Grandstream GWN7662 Hybrid 802.11ax Wi-Fi 6 Access Point (2×2 2.4GHz, 4×4 5.0 GHz)

The GWN7662 is an 802.11ax Wi-Fi 6 access point ideal for small-to-medium sized businesses, home offices, retail shops, restaurants, hospitality, education and more. It offers 4×4:4 MU-MIMO technology on the 5G band and 2×2:2 MU-MIMO on the 2.4G band as well as a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. Wi-Fi 6 technology supports the modern generation of dense environments where many users and many devices require consistent and reliable Wi-Fi connections at higher speeds. To ensure easy installation and management, the GWN7662 uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface. The GWN7662 is also supported by GWN.Cloud and GWN Manager, Grandstream’s free cloud and on premise Wi-Fi management platform. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 256 concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the GWN7662 is the ideal Wi-Fi access point for medium wireless network deployments with medium user density.

Features:

• 5.38 Gbps wireless throughput and 3.5 Gigabit wireline ports
• 5GHz 4×4:4 MU-MIMO with DL/UL OFDMA technology
• Up to 175-meter coverage range
• Supports 256 concurrent Wi-Fi client devices
• Advanced QoS to ensure real-time performance of low-latency applications
• Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
• Self power adaptation upon auto detection of PoE or PoE+
• Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise based software controller

Additional Information:

• Weight: 2 lb
• Dimensions: 10.16 × 9.72 × 3.39 in
• WiFi Standard: Wi-Fi 6 (802.11ax)
• Network Band: Dual Band
• Frequency Band: 2.4 Ghz, 5 Ghz
• Mounting Options: Ceiling, Wall Plate

Technical Specifications:

GENERAL INFO:

• Model: GWN7662
• Box Contents:
  •  GWN7662 indoor Wi-Fi 6 Wireless AP
  • Mounting Kits
  • Quick Installation Guide

WI-FI:

• Wi-Fi Standards:
  • IEEE 802.11 a/b/g/n/ac(Wave-2)/ax
• Antennas:
  • 6 single frequency internal antennas
  • 2.4GHz, gain 3.5dBi
  • 5GHz, gain 4.5dBiWi-Fi Data Rates:
• • 5G:
    IEEE802.11ax:8.6Mbps to 4804Mbps
    IEEE 802.11ac: 6.5 Mbps to 3464 Mbps
    IEEE 802.11n: 6.5Mbps to 600Mbps
    IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • 2.4G:
    IEEE 802.11ax:8.6Mbps to 573.5Mbps
    IEEE 802.11n: 6.5Mbps to 300Mbps
    IEEE 802.11b: 1, 2, 5.5, 11 Mbps
    IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
    *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio
    interference in the operating environment and mix of devices in the network
• Frequency Bands:
  • 2.4GHz Radio: 2412 – 2484 MHz(WIFI)
  • 5GHz Radio: 5180 – 5825 MHz
    *Not all frequency bands can be used in all regions
• Channel Bandwidth:
  • 2.4G: 20 and 40 MHz
  • 5G: 20, 40 , 80 and 160MHz
• Wi-Fi and System Security:
  • WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/
    control lockdown via digital signatures, unique security certificate and random default password per device
• MIMO:
  • 2×2:2 2.4GHz (MU-MIMO)
  • 4×4:4 5GHz (MU-MIMO)
• Coverage Range:
  • Up to 175 meters
    *Coverage range can vary based on environment

For a full list of specifications, please refer to the Product Data Sheet.
